Nissan Quest III (2003-2009) washer fluid level switch Wiring diagrams

70 67 BAT GND B+ B+ CPU GND GND CAN-L CAN-H BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FRONT WIPER HI RELAY FRONT WIPER MOTOR (LEFT REAR OF ENGINE COMPT) FRONT WIPER RELAY FRONT, REAR WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT) FUSE 14 FUSE 16 FUSE 39 FUSE 34 FUSE 41 FUSE 47 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK J GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HI RLY IGI HOT AT ALL TIMES HOT IN ON OR START IGN IGNITION RELAY INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 IPDM E/R (RIGHT SIDE OF ENGINE COMPT) MOVE ORG/ WIRE OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 OUTPUT 5 PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RLY AUTO STOP SIDE OF DASH) STOP UNIFIED METER CONTROL UNIT WASH MTR WASHER FLUID LEVEL SWITCH WASHER IND WHT/BLK WIRE YEL/BLK WIRE YEL/RED WIRE

55 44 MTR OUTPUT AUTO STOP 70 67 BAT GND BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT BRN WIRE CASE EARTH COMBINATION METER COMBINATION SWITCH FRONT, REAR WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT) FUSE 14 FUSE 16 FUSE 47 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK J GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IGN INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 IPDM E/R (RIGHT SIDE OF ENGINE COMPT) LT BLU WIRE MOVE ORG/ WIRE OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 OUTPUT 5 REAR WIPER MOTOR (CENTER OF BACK DOOR) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SIDE OF DASH) STOP UNIFIED METER CONTROL UNIT WASH MTR WASHER FLUID LEVEL SWITCH WASHER IND WHT/BLK WIRE YEL/BLK WIRE YEL/RED WIRE
