Nissan Quest III (2003-2009) turn stop tail/ stop Wiring diagram
This page shows the only wiring diagram for the component.turn stop tail/ stop, which is found in the car Nissan Quest III (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn stop tail/ stop (1 of 1)
1 2 TAIL OUTPUT STOP/TURN LH OUTPUT
6 14 DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) PNK WIRE
67 70 57 60 61 GND BAT (F/L) BAT (FUSE) FLASHER OUT (LEFT) FLASHER OUT (RIGHT)
B+ STOP INPUT TURN RH IN 8 9
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
BRN WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM PNK WIRE
CORNER LAMP PARK
FUSE 16
FUSE 24
FUSE 4
FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK J
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE 3
HOT IN ACC OR ON
HOT IN ON OR START
LEFT REAR COMBINATION LAMP
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP TURN
RIGHT REAR COMBINATION LAMP
TAIL INPUT TURN LH IN GND STOP/TURN RH OUTPUT 4 5 6
TAIL/ STOP STOP TURN
TRAILER CONNECTOR
TRAILER TOW CONTROL UNIT (BEHIND LEFT REAR QUARTERPANEL)
TURN STOP TAIL/ STOP
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
