Nissan Quest III (2003-2009) pedal adjusting switch Wiring diagrams
This page contains all the electrical diagrams for the component. pedal adjusting switch, in which he is found in the car Nissan Quest III (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pedal adjusting switch (1 of 2)
1 2 3 4 5 6 7 GND
A/T DEVICE (PARK POSITION SWITCH) (UNDER CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CIRCUIT BREAKER 2 (AT LEFT KICK PANEL)
DETENT SW IGN SW BAT (PTC)
FUSE 1
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK M
FWD RWD PEDAL ADJUSTING MOTOR (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
OTHER
PED MTR OUT
PEDAL ADJUSTING CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
PEDAL ADJUSTING SWITCH
PPL
RED WIRE
RED/WHT WIRE
RWD ILLUM
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Adjustable pedal circuit -> PEDAL ADJUSTING SWITCH
Wiring diagram pedal adjusting switch (2 of 2)
11 8 PPL
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BWD
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
LEFT DOOR MIRROR (AT MIRROR)
LT BLU WIRE
ORG/ WIRE
PEDAL ADJUSTING MOTOR (BEHIND LEFT SIDE OF DASH)
PEDAL ADJUSTING SWITCH
PPL
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Memory systems circuit (2 of 3) -> PEDAL ADJUSTING SWITCH
