Nissan Quest III (2003-2009) left sliding door remote control switch Wiring diagram

33 34 35 36 37 38 OPEN CLUTCH AUTOMATIC BACK DOOR CIRCUIT BACK DOOR CONTROL UNIT (BEHIND LEFT REAR QUARTERPANEL) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE CHILD LOCKOUT SWITCH CIRCUIT BREAKER 2 (AT LEFT KICK PANEL) CLM (+) BAT (C/B) DOOR UNLOCK ALL CLOSE CLUTCH RET COMPARTMENT) FUEL DOOR INTERLOCK SWITCH (BEHIND LEFT REAR QUARTER- PANEL) FULL LATCH SWITCH FUSE 12 FUSE 17 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE FUSIBLE LINK M GND GND GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/PNK WIRE GRN/YEL WIRE GRY/BLU WIRE HALF SWITCH HANDLE SWITCH HOT AT ALL TIMES HOT IN ON OR START LEFT CINCH LATCH MOTOR (REAR OF SLIDING DOOR) LEFT CINCH LATCH SWITCH (REAR OF SLIDING DOOR) LEFT LATCH RELEASE ACTUATOR (FRONT OF SLIDING DOOR) LEFT SLIDING DOOR CLUTCH LEFT SLIDING DOOR CONTROL UNIT (BEHIND LEFT REAR QUARTERPANEL) LEFT SLIDING DOOR LATCH CONTROL UNIT (CENTER OF SLIDING DOOR) LEFT SLIDING DOOR LOCK ACTUATOR (FRONT OF SLIDING DOOR) LEFT SLIDING DOOR MOTOR LEFT SLIDING DOOR MOTOR ASSEMBLY (BEHIND LEFT REAR QUARTERPANEL) LEFT SLIDING DOOR OPEN/CLOSE SWITCH (AT LEFT "B" PILLAR) LEFT SLIDING DOOR REMOTE CONTROL SWITCH LEFT SLIDING DOOR SWITCH (AT LEFT LEFT SLIDING "C" PILLAR) DOOR ENCODER LOCK LOCK SWITCH LOCK MOTOR LOCK MTR (-) CLM (-) GND LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NEUTRAL SWITCH ORG/BLK WIRE PPL PPL 1 2 3 4 5 6 7 PWR BAT (FUSE) FUEL DR SW S/DOOR SW OPEN/CLOSE SW CHILD LOCKOUT SW SIG-B PARK SW RED WIRE RED/GRN WIRE RED/WHT WIRE UNLOCK WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
