Nissan Quest III (2003-2009) gnd ign 6 sig ign 4 sig ign 2 sig gnd a Wiring diagram

ACCELERATOR PEDAL POSITION (APP) SENSOR (BEHIND LEFT SIDE OF DASH) ASCD ST SW AVCC BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN/WHT WIRE CAN L CAN-H CDCV COMPUTER DATA LINES SYSTEM CONDENSER 2 (NEAR BASE OF RIGHT "B" PILLAR) CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ECM (AT RIGHT REAR OF ENGINE COMPT) ECM GND ECM GND EVAP CANISTER VENT CONTROL VALVE (UNDER LEFT REAR OF VEHICLE) F PMP RLY FUEL LEVEL SENSOR UNIT, FUEL PUMP (IN FUEL TANK) FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) GND A AVCC PSPRES TPS 2 PDPRES GND IGN 6 SIG IGN 4 SIG IGN 2 SIG GND A GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES FUSE 20 HOT AT ALL TIMES FUSE 35 HOT IN ON OR START FUSE 12 HOT IN ON OR START FUSE 16 KLINE CAN L PNK WIRE LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PARK/ NEUTRAL POSITION SWITCH (ON TRANSAXLE) PNK WIRE POWER STEERING PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT) P_N_SW RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE SEN GND SENSOR 1 SENSOR 2 SSOFF STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH) STP LP SW NEUTL TC MTR RLY TF ASCD BRK SW IGN SW TRANSMISSION CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) VB VB BATT WHT WIRE WHT/BLK WIRE YEL/BLK WIRE YEL/RED WIRE
