Nissan Quest III (2003-2009) encoder, limit sw gnd Wiring diagram
This page shows the only wiring diagram for the component.encoder, limit sw gnd, which is found in the car Nissan Quest III (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram encoder, limit sw gnd (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
DOOR SW (AS) BUS IGN
DOOR SW (DR)
DOWN UP
ENCODER
ENCODER, LIMIT SW GND
FUSE 16
FUSE 4
FUSE BLOCK
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK J
GND PWR WIN PWR SUPP (RAP) PWR WIN PWR SUPP (BAT) BAT 68 69
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LIMIT SW ENCODER POWER PULSE
LIMIT SWITCH
POWER WINDOW SERIAL LINK
PPL
PPL 11 12 22 38
RED WIRE
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER WINDOW MOTOR (CENTER OF RIGHT FRONT DOOR)
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power windows circuit, with rear power vent windows (1 of 2) -> ENCODER, LIMIT SW GND
