Nissan Quest III (2003-2009) cpu a/c comp can-l can-h Wiring diagrams
This page contains all the electrical diagrams for the component. cpu a/c comp can-l can-h, in which he is found in the car Nissan Quest III (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cpu a/c comp can-l can-h (1 of 2)
7 9 22 9 CAN-H CAN-L PNK WIRE
73 67 70 49 TW GND A PDPRESS AVCC
A/C COMPRESSOR
A/C RELAY
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (RIGHT REAR OF ENGINE COMPT)
B+ FAN 2 FAN 3 FAN 1 MTR MTR MTR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN/YEL WIRE
CAN-H CAN-L PNK WIRE
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1
COOLING FAN RELAY 2
COOLING FAN RELAY 3
CPU A/C COMP CAN-L CAN-H
ECM (RIGHT REAR OF ENGINE COMPT)
ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
FUSE 33
FUSE 34
FUSE 41
FUSIBLE LINK G
FUSIBLE LINK H
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT)
HOT IN ON OR START
IG+ GND GND (SIGNAL) (POWER)
IGNITION RELAY
INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM (IPDM E/R) (RIGHT SIDE OF
PNK WIRE
RED WIRE
RED/YEL WIRE
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
W/ VDC W/O VDC
WHT WIRE
WHT/BLU WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> CPU A/C COMP CAN-L CAN-H
Wiring diagram cpu a/c comp can-l can-h (2 of 2)
7 9 22 9 CAN-H CAN-L PNK WIRE
73 67 70 49 TW GND A PDPRESS AVCC
A/C COMPRESSOR
A/C RELAY
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (RIGHT REAR OF ENGINE COMPT)
B+ FAN 2 FAN 3 FAN 1 MTR MTR MTR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN/YEL WIRE
CAN-H CAN-L PNK WIRE
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1
COOLING FAN RELAY 2
COOLING FAN RELAY 3
CPU A/C COMP CAN-L CAN-H
ECM (RIGHT REAR OF ENGINE COMPT)
ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
FUSE 33
FUSE 34
FUSE 41
FUSIBLE LINK G
FUSIBLE LINK H
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT)
HOT IN ON OR START
IG+ GND GND (SIGNAL) (POWER)
IGNITION RELAY
INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM (IPDM E/R) (RIGHT SIDE OF
PNK WIRE
RED WIRE
RED/YEL WIRE
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
W/ VDC W/O VDC
WHT WIRE
WHT/BLU WIRE
YEL/BLK WIRE
Go to component -> Manual a/c circuit (3 of 3) -> CPU A/C COMP CAN-L CAN-H
