Nissan Quest III (2003-2009) changeover switch Wiring diagram
This page shows the only wiring diagram for the component.changeover switch, which is found in the car Nissan Quest III (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram changeover switch (1 of 1)
AUTO ANTI-DAZZLING INSIDE MIRROR
BLK WIRE
BLU WIRE
CHANGEOVER SWITCH
DEFOGGER SYSTEM
DEFOGGER SYSTEM (BEHIND LEFT END OF DASH)
DOOR MIRROR REMOTE CONTROL SWITCH
DOWN
FUSE 14
FUSE 3
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE 6
HOT IN ON OR START
LEFT
LEFT DOOR MIRROR (AT MIRROR)
LT BLU WIRE
MIRROR SWITCH OFF
OFF
ORG/ WIRE
PPL
RED WIRE
RIGHT
RIGHT DOOR MIRROR (AT MIRROR)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power mirrors circuit -> CHANGEOVER SWITCH
