Nissan Quest III (2003-2009) b+ b+ cpu gnd gnd can-l can-h Wiring diagram
This page shows the only wiring diagram for the component.b+ b+ cpu gnd gnd can-l can-h, which is found in the car Nissan Quest III (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b+ b+ cpu gnd gnd can-l can-h (1 of 1)
70 67 BAT GND
B+ B+ CPU GND GND CAN-L CAN-H
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FRONT WIPER HI RELAY
FRONT WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
FRONT WIPER RELAY
FRONT, REAR WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT)
FUSE 14
FUSE 16
FUSE 39 FUSE 34 FUSE 41
FUSE 47
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK J
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HI RLY IGI
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IGNITION RELAY
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
IPDM E/R (RIGHT SIDE OF ENGINE COMPT)
MOVE
ORG/ WIRE
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RLY AUTO STOP
SIDE OF DASH)
STOP
UNIFIED METER CONTROL UNIT
WASH MTR
WASHER FLUID LEVEL SWITCH
WASHER IND
WHT/BLK WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Front wiper/washer circuit -> B+ B+ CPU GND GND CAN-L CAN-H
