Nissan Quest III (2003-2009) 19 20 18 signal pwr signal sig gnd Wiring diagram

19 20 18 SIGNAL PWR SIGNAL SIG GND 43 47 48 DOOR LIFT GATE DOOR SW (DR) DOOR SW (RL) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 16 FUSE 19 FUSE 3 FUSE 4 FUSE BLOCK FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK J GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INSERTED KEY SWITCH LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT SLIDING DOOR SWITCH (AT LEFT "C" PILLAR) ORG/ WIRE ORG/BLK WIRE PNK 1 2 3 4 SIGNAL GND SIGNAL WIRE PNK HEADLIGHTS SYSTEM WIRE PNK WIRE POWER WINDOW SERIAL LINK POWER WINDOWS SYSTEM PPL PPL/WHT WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE REMOTE KEYLESS ENTRY RECEIVER (BEHIND RIGHT END OF DASH) REMOVED RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR) RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT SLIDING DOOR SWITCH (AT RIGHT "C" PILLAR) SIGNAL PWR UNLOCK LOCK W/ BACK DOOR AUTOMATIC SLIDING DOOR SYSTEM W/O BACK DOOR AUTOMATIC SLIDING DOOR SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
