Instrument illumination circuit for Nissan Quest II (1999-2002)

A/C CONTROL UNIT (ILLUMI- NATION) (W/O EATC) ASCD MAIN SWITCH (ILLUMI- NATION) AUDIO UNIT ILLUMINATION BLK WIRE BLU WIRE BLU/RED WIRE BRIGHTER COMBINATION METER (ILLUMI- NATION) DARKER DIODE 2 (IN LEFT FRONT DOOR) DOOR MIRROR REMOTE CONTROL SWITCH (ILLUMI- NATION) EATC UNIT (ILLUMI- NATION) A/C CONTROL UNIT (ILLUMI- NATION) FUSE 18 FUSE 5 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRY/RED WIRE HAZARD SWITCH (ILLUMI- NATION) ASHTRAY (ILLUMI- NATION) HEADLAMP CONTROL UNIT (AT RIGHT SIDE OF DRIVER'S FOOTWELL) HOT AT ALL TIMES HOT IN ACC OR ON ILL CTRL OUTPUT ILL CTRL SW DARKER ILL CTRL SW LIGHTER ILLUMINATION CONTROL SWITCH, AUTOLAMP SWITCH (ILLUMINATION) J/C 2 (BEHIND LEFT SIDE OF DASH) J/C 3 (BEHIND LEFT SIDE OF DASH) LIGHTING SWITCH LIGHTING SWITCH (ILLUMI- NATION) LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH (ILLUMI- NATION) OFF PNK PNK PNK WIRE PNK PNK WIRE PNK W/O EATC W/EATC WIRE PNK WIRE PNK/BLK WIRE REAR AUDIO REMOTE CONTROL UNIT (ILLUMI- NATION) REAR FAN SWITCH (FRONT) (ILLUMI- NATION) REAR FAN SWITCH (REAR) (ILLUMI- NATION) REAR WIPER SWITCH (ILLUMI- NATION) REAR WINDOW DEFOGGER SWITCH (ILLUMI- NATION) RED WIRE RED/WHT WIRE RIGHT DOOR LOCK/ UNLOCK SWITCH (ILLUMI- NATION) RIGHT FRONT POWER WINDOW SWITCH (ILLUMI- NATION) TAILLAMP TAILLAMP RELAY
