Nissan Quest II (1999-2002) turn tail Wiring diagram
This page shows the only wiring diagram for the component.turn tail, which is found in the car Nissan Quest II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn tail (1 of 1)
BLK WIRE
COMBINATION FLASHER UNIT (BEHIND LEFT SIDE OF DASH)
COMBINATION SWITCH 2 (TURN SIGNAL SWITCH)
FUSE 23
FUSE 27
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/YEL WIRE
GROUND
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN START OR RUN
ILLUMINATION LAMP
INSTRUMENT CLUSTER
JOINT CONNECTOR 4 (IN FUSE AND FUSIBLE LINK BOX)
LEFT FRONT TURN SIGNAL LAMP
LEFT REAR COMBINATION LAMP TAIL STOP TURN
LEFT RIGHT
LEFT TURN IND
OFF ON
ORG/ WIRE
OUT
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/WHT WIRE
POWER
PPL
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT REAR COMBINATION LAMP STOP
RIGHT TURN IND
TURN TAIL
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> TURN TAIL
