Nissan Quest II (1999-2002) starting/ charging system Wiring diagrams
This page contains all the electrical diagrams for the component. starting/ charging system, in which he is found in the car Nissan Quest II (1999-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram starting/ charging system (1 of 2)
AIR VALVE
ASCD ACTUATOR (RIGHT SIDE OF ENGINE COMPT)
ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
ASCD CONTROL UNIT (RIGHT SIDE OF DRIVER'S FOOTWELL)
ASCD HOLD RELAY (ON RELAY BOX, LEFT FRONT CORNER OF ENGINE COMPARTMENT)
ASCD MAIN SWITCH
ASCD STEERING SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
COMBINATION METER
CRUISE IND
CRUISE SWITCH OD CUT SIGNAL
FUSE 22
FUSE 29
FUSE 42
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HORN RELAY (ON RELAY BOX)
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM- INATION
INTERIOR LIGHTS
J/C 4 (IN FUSE, FUSIBLE LINK BOX)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/RED WIRE
OFF
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION RELAY (ON RELAY BOX)
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PPL/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RELEASE VALVE
RESUME/ ACCELERATE
SET/COAST
SPEED- OMETER
SPIRAL CABLE
STARTING/ CHARGING SYSTEM
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
SYSTEM
TRANSMISSION CONTROL MODULE (TCM) (BEHIND DASH, RIGHT OF STEERING COLUMN)
VACUUM VALVE
VEHICLE SPEED SENSOR (ON TRANSAXLE)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/LT BLU WIRE
Go to component -> Cruise control circuit -> STARTING/ CHARGING SYSTEM
Wiring diagram starting/ charging system (2 of 2)
AUTO 1 AUTO 2
AUTOLAMP SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMBINATION SWITCH 1
FUSE 12
FUSE 30
FUSE 36
FUSE BLOCK (LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT) FUSE 37
GRN WIRE
GRN/BLK WIRE
GRY/RED WIRE
HEADLAMP CONTROL UNIT
HIGH BEAM INDICATOR
HIGH BEAM LOW BEAM
HOT AT ALL TIMES
HOT IN
HOT IN ON OR START
ILLUMINATON
INSTRUMENT CLUSTER
J/C 2 (BEHIND LEFT SIDE OF DASH)
LEFT HEADLAMP
LIGHTING SWITCH
LOW BEAM
LT GRN WIRE
LT GRN/RED WIRE
OFF
ORG/ WIRE
ORG/BLU WIRE
ORG/WHT WIRE
PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PASS
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLAMP HIGH BEAM
SMART ENTRANCE CONTROL UNIT
STARTING/ CHARGING SYSTEM
W/ AUTO- LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, with drl -> STARTING/ CHARGING SYSTEM
