Nissan Quest II (1999-2002) room lamp zone a Wiring diagram
This page shows the only wiring diagram for the component.room lamp zone a, which is found in the car Nissan Quest II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram room lamp zone a (1 of 1)
BACK DOOR LAMP
BACK DOOR LATCH SWITCHES
BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/WHT WIRE
DOOR
FRONT PERSONAL LAMP
FRONT ROOM LAMP
FUSE 21
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GLOVE BOX LAMP)
HOT AT ALL TIMES
INTERIOR LIGHTING SIGNAL
J/C 3 (BEHIND LEFT SIDE OF DASH)
J/C 4 (IN FUSE, FUSIBLE LINK BOX, LEFT FRONT OF ENG COMPT)
KEY SWITCH
LEFT BACK DOOR LATCH SWITCH
LEFT DOOR SWITCH
LEFT FOOT LAMP
LEFT FRONT DOOR SWITCH
LEFT FRONT STEP LAMP
LEFT SLIDING DOOR STEP LAMP
LEFT SLIDING DOOR SWITCH
LEFT VANITY LAMP
LIGHTING SWITCH
MAP LAMP
OFF
ON OFF
ORG/ WIRE
REAR PERSONAL LAMP
REAR ROOM LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT BACK DOOR LATCH SWITCH
RIGHT DOOR SWITCH SLIDING DOOR SWITCHES
RIGHT FOOT LAMP
RIGHT FRONT DOOR SWITCH
RIGHT FRONT STEP LAMP
RIGHT SLIDING DOOR STEP LAMP
RIGHT SLIDING DOOR SWITCH
RIGHT VANITY LAMP
ROOM LAMP ZONE A
ROOM LAMP ZONE B
ROOM LAMP ZONE C
SMART ENTRANCE CONTROL UNIT (BEHIND CENTER OF DASH)
WHT WIRE
Go to component -> Courtesy lamps circuit -> ROOM LAMP ZONE A
