Nissan Quest II (1999-2002) left sliding door switch Wiring diagrams

This page contains all the electrical diagrams for the component. left sliding door switch, in which he is found in the car Nissan Quest II (1999-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left sliding door switch (1 of 3)

Wiring diagram left sliding door switch for Nissan Quest II (1999-2002) (1 of 3)

Get access

5 6 PPL 7 5 UNLK BLK WIRE BLK/PNK WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE CIRCUIT BREAKER 1 (BEHIND LEFT KICK PANEL) FUSE 23 FUSE 30 FUSE 39 FUSE 5 FUSE BLOCK (LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT) GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HEADLIGHTS SYSTEM HOOD SWITCH HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START J/C 4 (IN FUSE, FUSIBLE LINK BOX) KEY SWITCH LEFT BACK DOOR LATCH SWITCH RIGHT BACK DOOR LATCH SWITCH LEFT FRONT DOOR SWITCH LEFT SLIDING DOOR SWITCH LOCK LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH MEMORY SYSTEMS HORNS SYSTEM PNK/WHT WIRE PPL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DOOR LOCK/ UNLOCK SWITCH RIGHT FRONT DOOR SWITCH RIGHT SLIDING DOOR SWITCH SECURITY INDICATOR LAMP SMART ENTRANCE CONTROL UNIT (BEHIND CENTER OF DASH) STARTING/CHARGING SYSTEM THEFT WARNING RELAY (ON RELAY BOX) UNLK WHT/GRN WIRE WHT/RED WIRE YEL WIRE

Go to component -> Anti-theft circuit (1 of 2) -> LEFT SLIDING DOOR SWITCH

Wiring diagram left sliding door switch (2 of 3)

Wiring diagram left sliding door switch for Nissan Quest II (1999-2002) (2 of 3)

Get access

BACK DOOR LAMP BACK DOOR LATCH SWITCHES BLK WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE DOOR FRONT PERSONAL LAMP FRONT ROOM LAMP FUSE 21 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GLOVE BOX LAMP) HOT AT ALL TIMES INTERIOR LIGHTING SIGNAL J/C 3 (BEHIND LEFT SIDE OF DASH) J/C 4 (IN FUSE, FUSIBLE LINK BOX, LEFT FRONT OF ENG COMPT) KEY SWITCH LEFT BACK DOOR LATCH SWITCH LEFT DOOR SWITCH LEFT FOOT LAMP LEFT FRONT DOOR SWITCH LEFT FRONT STEP LAMP LEFT SLIDING DOOR STEP LAMP LEFT SLIDING DOOR SWITCH LEFT VANITY LAMP LIGHTING SWITCH MAP LAMP OFF ON OFF ORG/ WIRE REAR PERSONAL LAMP REAR ROOM LAMP RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT BACK DOOR LATCH SWITCH RIGHT DOOR SWITCH SLIDING DOOR SWITCHES RIGHT FOOT LAMP RIGHT FRONT DOOR SWITCH RIGHT FRONT STEP LAMP RIGHT SLIDING DOOR STEP LAMP RIGHT SLIDING DOOR SWITCH RIGHT VANITY LAMP ROOM LAMP ZONE A ROOM LAMP ZONE B ROOM LAMP ZONE C SMART ENTRANCE CONTROL UNIT (BEHIND CENTER OF DASH) WHT WIRE

Go to component -> Courtesy lamps circuit -> LEFT SLIDING DOOR SWITCH
