Nissan Quest II (1999-2002) 10 9 8 7 6 5 4 3 2 1 high wash low park Wiring diagram
This page shows the only wiring diagram for the component.10 9 8 7 6 5 4 3 2 1 high wash low park, which is found in the car Nissan Quest II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 10 9 8 7 6 5 4 3 2 1 high wash low park (1 of 1)
10 9 8 7 6 5 4 3 2 1 HIGH WASH LOW PARK
BLK WIRE
BLK/WHT WIRE
BLU/ORG WIRE
BRN/WHT WIRE
COMBINATION SWITCH (WIPER SWITCH)
FRONT WASHER MOTOR (IN WASHER FLUID RESERVOIR)
FRONT WIPER AMPLIFIER
FRONT WIPER MOTOR (LEFT SIDE OF FIREWALL)
FUSE 8
FUSE BLOCK (LEFT OF STEERING COLUMN)
GRN WIRE
GROUND GROUND WIPER SW WIPER SW WIPER SW
HOT IN ACC OR ON
J/C 4 (IN FUSE, FUSIBLE LINK BOX)
LO HI
OFF
PNK WIRE
RED WIRE
WASH
WHT WIRE
YEL/RED WIRE
Go to component -> Front washer/wiper circuit -> 10 9 8 7 6 5 4 3 2 1 HIGH WASH LOW PARK
