Nissan Quest I (1992-1998) rear wiper switch Wiring diagrams
This page contains all the electrical diagrams for the component. rear wiper switch, in which he is found in the car Nissan Quest I (1992-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear wiper switch (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
FUSE 9
GLASS HATCH SWITCH (CENTER OF LIFTGATE)
HOT AT ALL TIMES FUSE BLOCK (LEFT SIDE OF DASH) FUSE 2
HOT IN ACC OR ON
PNK WIRE
PNK/BLK WIRE
PPL
REAR WASHER MOTOR (IN WASHER FLUID RESERVOIR)
REAR WIPER AMPLIFIER
REAR WIPER MOTOR (ON CENTER OF BACK DOOR)
REAR WIPER SWITCH
WASHER SWITCH
WIPER SWITCH
YEL/BLK WIRE
Go to component -> Rear wiper/washer circuit, with moveable liftgate glass -> REAR WIPER SWITCH
Wiring diagram rear wiper switch (2 of 2)
1 2 3 4 5 6 7 8 WIPER ON INPUT
BLK WIRE
BLU WIRE
BLU/YEL WIRE
HOT IN ACC OR ON FUSE BLOCK (LEFT SIDE OF DASH) FUSE 9
MOTOR CONTROL WASH GROUND
PARK
PNK WIRE
PNK/BLK WIRE
REAR WASHER MOTOR (RIGHT FRONT FENDER)
REAR WIPER AMPLIFIER (LEFT REAR WHEEL WELL)
REAR WIPER MOTOR (CENTER OF LIFTGATE)
REAR WIPER SWITCH
WASHER SWITCH
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Rear wiper/washer circuit, without moveable liftgate glass -> REAR WIPER SWITCH
