Nissan Quest I (1992-1998) radio/ cassette player Wiring diagrams
This page contains all the electrical diagrams for the component. radio/ cassette player, in which he is found in the car Nissan Quest I (1992-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram radio/ cassette player (1 of 2)
17 18 19 20 21 22 23 24 BAT (BACKUP) ILL CONTROL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
FUSE 10
FUSE 20
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
NCA WIRE
ORG/ WIRE
PNK INTERIOR LIGHTS SYSTEM LIGHTING SWITCH WIRE
PNK/BLK WIRE
RADIO/ CASSETTE PLAYER
RED WIRE
RED/BLU WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
ROD ANTENNA
WHT WIRE
WINDOW ANTENNA
YEL WIRE
YEL/BLU WIRE
Go to component -> Base radio -> RADIO/ CASSETTE PLAYER
Wiring diagram radio/ cassette player (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 RRSP (+) RRSP (-)
1 2 3 4 5 6 7 8 9 10 11 12 ACP A SHIELD GND
17 18 19 20 21 22 23 24 BAT ILL (-) INTERIOR LIGHTS SYSTEM
25 26 27 28 MUTE OUTPUT SUB WOOFER OUT (+) SHIELD SUB WOOFER OUT (-)
25 26 VOL (+)/NEXT VOL (-)/NEXT
4-CHANNEL AMPLIFIER (IF EQUIPPED) (BEHIND TRIM PANEL, ABOVE LEFT REAR WHEELWELL)
ASYSON
ASYSON RFSP (+) RFSP (-) RRSP (+) RRSP (-) ACP B
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
CD CHANGER (IF EQUIPPED) (RIGHT SIDE OF DASH)
DIN CORD
FUSE 10
FUSE 11
FUSE 20
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GND ACP B ACP A PPL
GND ANT-SIGNAL PAE POWER ANTENNA SYSTEM
GRN WIRE
GROUND
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
INPUT (+) 2 3 4 5 6
LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER
LFSP (+) RRSP (+) RFSP (-) RFSP (+) LRSP (-) LRSP (+) LFSP (-)
LT GRN WIRE
MUTE INPUT INPUT (-)
NCA WIRE
NEXT
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PNK INTERIOR LIGHTS SYSTEM ILL (+) WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL ACP B ASYSON BAT
RADIO/ CASSETTE PLAYER
REAR RADIO REMOTE CONTROL UNIT (IF EQUIPPED) (BEHIND DRIVER'S SEAT)
RED WIRE
RED/BLU WIRE
RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER
ROD ANTENNA
RRSP (-) 16 17 18 19 20 21 22 23 24
RRSP (-) RRSP (+) RFSP (+) RFSP (-) LRSP (-) LRSP (+) LFSP (+) LFSP (-)
SHIELD ILL (-) ILL (+) LRSP (-) LRSP (+)
SHIELD LFSP (+) LFSP (-) LRSP (+) LRSP (-) ACP A
SPIRAL CABLE
STEERING WHEEL RADIO CONTROL SWITCHES (IF EQUIPPED)
SUB WOOFER SPEAKER
UN-MUTE GND
VOLUME-
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDOW ANTENNA
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Premium sound radio circuit -> RADIO/ CASSETTE PLAYER
