Nissan Quest I (1992-1998) l rear wheel spd sens l rear wheel spd sens ground rt fnt wheel spd sens Wiring diagram
This page shows the only wiring diagram for the component.l rear wheel spd sens l rear wheel spd sens ground rt fnt wheel spd sens, which is found in the car Nissan Quest I (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram l rear wheel spd sens l rear wheel spd sens ground rt fnt wheel spd sens (1 of 1)
1995 VFTC
ANTI-LOCK WARNING INDICATOR
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRAKE ON/OFF (BOO) SWITCH (TOP OF BRAKE PEDAL SUPPORT)
BRN WIRE
DATA LINK CONNECTOR #2 (BEHIND LEFT SIDE OF I/P)
FUSE 22
FUSE 29
FUSE 30
FUSE AND FUSIBLE LINK BOX
FUSE BLOCK
FUSIBLE LINK B FUSE 43
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND RT FNT SOL OUTPUT
GROUND RT FNT WHEEL SPD SENS
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
HYDRAULIC ACTUATOR ASSEMBLY (RIGHT FRONT OF ENGINE COMPARTMENT)
INSTRUMENT CLUSTER
L FNT WHEEL SPD SENS L FNT WHEEL SPD SENS
L REAR WHEEL SPD SENS L REAR WHEEL SPD SENS GROUND RT FNT WHEEL SPD SENS
LEFT FRONT SOLENOID
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LT GRN WIRE
MOTOR RELAY
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
PNK WIRE
PPL
PPL SOL RETURN
PUMP MOTOR
PUMP MTR (HYDRAULIC)
REAR SOLENOID
RED WIRE
RIGHT FRONT SOLENOID
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
SOL RLY/MTR RLY REAR SOL OUTPUT
SOLENOID RELAY
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brake circuits -> L REAR WHEEL SPD SENS L REAR WHEEL SPD SENS GROUND RT FNT WHEEL SPD SENS
