Nissan Quest I (1992-1998) door switch input Wiring diagram
This page shows the only wiring diagram for the component.door switch input, which is found in the car Nissan Quest I (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door switch input (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CHIME CONTROL
DOOR SWITCH INPUT
FUSE 21
FUSE 29
FUSE 41
GRN WIRE
GRN/RED WIRE
GROUND
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
HOT IN RUN OR START FUSE BLOCK (LEFT SIDE OF I/P) FUSE 30
INSTRUMENT CLUSTER
JOINT CONNECTOR 2 (IN FUSE AND FUSIBLE LINK BOX)
JOINT CONNECTOR 3 (LEFT SIDE OF I/P)
JOINT CONNECTOR 5 (LEFT SIDE OF I/P)
KEY IN IGNITION INPUT
KEY SWITCH
LEFT DOOR JAMB SWITCH
LEFT FRONT FENDER)
LEFT REAR FENDER
LIGHT SWITCH
LT GRN WIRE
LT GRN/ORG WIRE
OFF HEAD
ORG/BLK WIRE
PARK
PPL/WHT WIRE
RED WIRE
RIGHT REAR FENDER
SEAT BELT BUCKLE SWITCH
SEAT BELT WARNING LAMP
SEATBELT SWITCH INPUT
TIMER MODULE (BEHIND BOTTOM OF LEFT COWL PANEL) IGNITION
WARNING CHIME (LEFT SIDE OF I/P)
Go to component -> Warning system circuits -> DOOR SWITCH INPUT
