Nissan Patrol Y62 facelift 2 (2019-2024) seat heater input switch Wiring diagram
This page shows the only wiring diagram for the component.seat heater input switch, which is found in the car Nissan Patrol Y62 facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat heater input switch (1 of 1)
A/C AUTOMATIC AMPLIFIER
BLK WIRE
BLK/ORG WIRE
BRN WIRE
COMBINATION SWITCH
FUSE 76
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK HOLDER 2
GRN WIRE
HEATED STEERING WHEEL
HEATED STEERING WHEEL RELAY
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
IND
NCA WIRE
RED WIRE
SEAT HEATER INPUT SWITCH
STRG HEATER OUT
THERMOSTAT
TRIPLE SWITCH
WHT WIRE
Go to component -> Heated steering wheel circuit -> SEAT HEATER INPUT SWITCH
