Nissan Patrol Y62 facelift 2 (2019-2024) left fold down switch Wiring diagrams
This page contains all the electrical diagrams for the component. left fold down switch, in which he is found in the car Nissan Patrol Y62 facelift 2 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left fold down switch wiring diagram (1 of 2)
A/C AUTOMATIC AMPLIFIER
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
AUTO ANTI-DAZZLING INSIDE MIRROR
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC BACK DOOR WARNING BUZZER
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BOSE AMPLIFIER
COMBINATION SWITCH
DRIVER SIDE SEAT BACK HEATER DRIVER SIDE FRONT SEAT
FROM FUSE 11 (DIAGRAM 2 OF 8)
FROM FUSE, FUSIBLE LINK BLOCK (DIAGRAM 1 OF 8)
FRONT A/C CONTROL
FUSE 1
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEATER, VENTILATION SEAT RELAY
ICC BRAKE HOLD RELAY
IGN RLY (F/B) CONT
IGNITION RELAY 1
IGNITION RELAY 2
INTELLIGENT REAR VIEW MIRROR
LEFT FOLD DOWN SWITCH
LEFT RECLINING SWITCH
LEFT SECOND HEATED SEAT SWITCH
LOW TIRE PRESSURE WARNING CONTROL UNIT
NCA WIRE
OCCUPANT DETECTION SYSTEM CONTROL UNIT
ORG/ WIRE
PASSENGER SIDE SEAT BACK HEATER PASSENGER SIDE FRONT SEAT
REAR A/C CONTROL
REAR A/C RELAY
REAR BLOWER MOTOR
RED WIRE
RED/BLU WIRE
RIGHT FOLD DOWN SWITCH
RIGHT RECLINING SWITCH
RIGHT SECOND HEATED SEAT SWITCH
SNOW MODE/ TOW MODE/ VDC OFF SWITCH ASSEMBLY
SONAR CONTROL UNIT
STOP LAMP RELAY
STOP LAMP SWITCH
TCU
TO ACCESSORY RELAY (DIAGRAM 2 OF 8)
TO DATA LINK CONNECTOR (DIAGRAM 8 OF 8)
TO ICC BRAKE SWITCH (DIAGRAM 8 OF 8)
W/ AUTOMATIC BACK DOOR
W/ FRONT HEATED SEAT
W/ INTELLIGENT REAR VIEW MIRROR
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 8) -> LEFT FOLD DOWN SWITCH
left fold down switch wiring diagram (2 of 2)
BACK- WARD
BLK WIRE
BLU WIRE
FOR- WARD
FUSE 9
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK HOLDER 2
FUSIBLE LINK S
GRN WIRE
HOT AT ALL TIMES
LEFT DOWN RELAY 1
LEFT DOWN RELAY 2
LEFT FOLD DOWN SWITCH
LEFT FOLDING MOTOR
LEFT RECLINING SWITCH
LEFT THIRD SEAT
LEFT UP RELAY 1
LEFT UP RELAY 2
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RIGHT DOWN RELAY 1
RIGHT DOWN RELAY 2
RIGHT FOLD DOWN SWITCH
RIGHT FOLDING MOTOR
RIGHT RECLINING SWITCH
RIGHT THIRD SEAT
RIGHT UP RELAY 1
RIGHT UP RELAY 2
WHT WIRE
YEL WIRE
Go to component -> Third row folding seat circuit -> LEFT FOLD DOWN SWITCH
