Nissan Patrol Y62 facelift 2 (2019-2024) back door open request sig Wiring diagram
This page shows the only wiring diagram for the component.back door open request sig, which is found in the car Nissan Patrol Y62 facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back door open request sig (1 of 1)
AS DOOR SW
BACK DOOR CONTROL UNIT (RIGHT SIDE OF TAILGATE)
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPEN REQUEST
BACK DOOR OPEN REQUEST SIG
BACK DOOR OPENER SW
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH ASSEMBLY
BACK DOOR REQUEST SW
BACK DOOR REQUEST SWITCH
BACK DOOR SW
BACK DOOR SWITCH
BAT (F/L) GND
BATT (+)B MTR OPEN PPL
BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CAN L
CAN-H
CLOSE SW PNK OPEN SW WIRE
CLOSE SWITCH
CLOSURE MOTOR
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 78
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK HOLDER 3
FUSIBLE LINK K
GRN WIRE
GRN/YEL WIRE
HALF LATCH SWITCH
HALF SW
HOT AT ALL TIMES
MTR (CLOSE)
ORG/ WIRE
PNK V CAN-L WIRE
PNK WIRE
PPL
RED WIRE
SWITCH
UNIFIED METER CONTROL UNIT
V CAN-H
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Back door circuit, w/o automatic back door system -> BACK DOOR OPEN REQUEST SIG
