Nissan Patrol Y62 facelift 2 (2019-2024) a/t shift selector Wiring diagram
This page shows the only wiring diagram for the component.a/t shift selector, which is found in the car Nissan Patrol Y62 facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t shift selector (1 of 1)
A/T SHIFT SELECTOR
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
AUTO ANTI-DAZZLING INSIDE MIRROR
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLK WIRE
BLK/YEL WIRE
DATA LINK CONNECTOR
DISPLAY UNIT
DRIVER SIDE VANITY MIRROR LAMP
FRONT CAMERA UNIT
GLOVE BOX LAMP)
INTELLIGENT REAR VIEW MIRROR
LEFT REAR CENTER CONSOLE USB POWER SOCKET
LEFT SECOND HEATED SEAT SWITCH
LT BLU WIRE
MAP LAMP
NATS ANTENNA AMPLIFIER
NCA WIRE
ORG/ WIRE
PASSENGER SIDE VANITY MIRROR LAMP
PERSONAL LAMP
PRESENT SWITCH
PUSH BUTTON IGNITION SWITCH
RIGHT REAR CENTER CONSOLE USB POWER SOCKET
RIGHT SECOND HEATED SEAT SWITCH
STEERING ANGLE SENSOR
SUNROOF SWITCH
TELEMATICS SWITCH
USB CONNECTOR
W/ INTELLIGENT REAR VIEW MIRROR
YAW RATE/ SIDE/DECEL G SENSOR
YEL WIRE
Go to component -> Ground distribution circuit (6 of 6) -> A/T SHIFT SELECTOR
