Nissan Patrol Y62 facelift 2 (2019-2024) accelerator pedal actuator/accelerator pedal position sensor Wiring diagram
This page shows the only wiring diagram for the component.accelerator pedal actuator/accelerator pedal position sensor, which is found in the car Nissan Patrol Y62 facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram accelerator pedal actuator/accelerator pedal position sensor (1 of 1)
A/C AUTOMATIC AMPLIFIER
A/T ASSEMBLY (ON TRANSMISSION)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ACCELERATOR PEDAL ACTUATOR/ACCELERATOR PEDAL POSITION SENSOR
BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CAN L
CAN TERMINATOR (CHASSIS CAN COMMUNICATION)
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER PNK WIRE
DATA LINK CONNECTOR
ECM (RIGHT REAR OF ENGINE COMPT)
FRONT CAMERA UNIT (INSIDE REAR VIEW MIRROR)
FUSE 3
FUSE 6
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
ITS COMM-H
ITS COMM-L
JOINT CONNECTOR
LOW TIRE PRESSURE WARNING CONTROL UNIT (RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
NCA WIRE
OCCUPANT DETECTION SYSTEM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
PNK WIRE
PNK/BLU WIRE
RED WIRE
STEERING ANGLE SENSOR (IN STEERING COLUMN)
TCM
TRANSFER CONTROL UNIT
UNIFIED METER CONTROL UNIT
V CAN-H
V CAN-L
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Computer data lines circuit (1 of 2) -> ACCELERATOR PEDAL ACTUATOR/ACCELERATOR PEDAL POSITION SENSOR
