Car Wiring Diagrams for Head-up display circuit for Nissan Pathfinder V (2021-2024)

AV CONTROL UNIT BLK WIRE BLU WIRE CAN-H CAN-H PPL CAN-L COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 48 FUSE 6 FUSE BLOCK (J/B) GRY WIRE HEAD UP DISPLAY UNIT HEAD-UP DISPLAY SWITCH HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED LT BLU WIRE LT GRN WIRE M CAN-H M CAN-H HEAD UP DISPLAY MAIN SW SIG PNK WIRE M CAN-L PNK WIRE PPL CAN-L PPL/PNK ACC PWR SUP WIRE PPL/PNK WIRE PPL/TAN WIRE RED WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER W/ TELEMATICS W/O BOSE AUDIO SYSTEM W/O TELEMATICS
