Nissan Pathfinder V (2021-2024) dual sensor regulator Wiring diagram
This page shows the only wiring diagram for the component.dual sensor regulator, which is found in the car Nissan Pathfinder V (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dual sensor regulator (1 of 1)
A/T FLUID TEMPERATURE SENSOR
AT UNIT (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BRAKE B PRESSURE REGULATOR
BRAKE C PRESSURE REGULATOR
BRAKE D PRESSURE REGULATOR
BRN WIRE
CLUTCH E PRESSURE REGULATOR
DOG CLUTCH A POSITION SENSOR
DOG CLUTCH A SOLENOID VALVE
DOG CLUTCH F POSITION SENSOR
DOG CLUTCH F SOLENOID VALVE
DRIVE MODE SWITCH
DUAL SENSOR REGULATOR
GRN WIRE
GRY WIRE
LINE PRESSURE CONTROL PRESSURE REGULATOR
LT BLU WIRE
LT GRN WIRE
PARK POSITION SENSOR
PARKING LOCK ACTUATOR
PARKING LOCK VALUE
PNK WIRE
PPL
RED WIRE
TORQUE CONVERTER CLUTCH PRESSURE REGULATOR
WHT WIRE
YEL WIRE
Go to component -> A/t circuit (3 of 3) -> DUAL SENSOR REGULATOR
