Car Wiring Diagrams for Cooling fan circuit for Nissan Pathfinder IV facelift (2016-2020)

BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY ENG COOL TEMP SENS ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FUSE 48 FUSE, FUSIBLE LINK, RELAY BOX 1 FUSE, FUSIBLE LINK, RELAY BOX 2 FUSIBLE LINK H GRN WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE PNK (OR WIRE PNK WIRE POWER PPL PWM CONT FAN RED WIRE REFRIGERANT PRESS SENS REFRIGERANT PRESSURE SENSOR SENS GND SENS PWR SPLY SIG WHT WIRE YEL WIRE
