Nissan Pathfinder IV facelift (2016-2020) warning system switch Wiring diagrams
This page contains all the electrical diagrams for the component. warning system switch, in which he is found in the car Nissan Pathfinder IV facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram warning system switch (1 of 3)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ADAS CONTROL UNIT
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 29
FUSE 30
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
LEFT BLIND SPOT WARNING INDICATOR
LEFT SIDE RADAR
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT BLIND SPOT WARNING INDICATOR
RIGHT END OF DASH)
RIGHT SIDE RADAR
SHIELD
SHIELD SHIELD
SPEAKER
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WARNING BUZZER
WARNING SYS SW
WARNING SYS SW LED
WARNING SYSTEM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> WARNING SYSTEM SWITCH
Wiring diagram warning system switch (2 of 3)
ADAS CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FEB OFF IND
FUSE 13
FUSE 29
FUSE 31
FUSE 38
FUSE 46
FUSE 55
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ECM RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
INPUT SPD SENS
INPUT SPEED SENSOR
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
ITS CAN-H
ITS CAN-L
LT GRN WIRE
OUTPUT SPD SENS
OUTPUT SPEED SENSOR
PNK WIRE
PRI SPD SENS
PRIMARY SPEED SENSOR
RED WIRE
RIGHT END OF DASH)
SPEAKER
STOP LP RLY DRIVE
SW LED
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
THROTTLE CONTROL MOTOR RELAY
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) CAN-L
VIGN
WARNING BUZZER
WARNING SYSTEM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> WARNING SYSTEM SWITCH
Wiring diagram warning system switch (3 of 3)
A/C, AV SWITCH ASSEMBLY
AUTOMATIC BACK DOOR MAIN SWITCH
AUTOMATIC BACK DOOR SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
FUSE 51
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
MOOD LAMP (CENTER CONTROL)
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
TAIL LAMP RELAY
TOW MODE SWITCH
TRIP RESET SWITCH
VDC OFF SWITCH
W/ DRIVER ASSISTANCE SYSTEM
W/ MEMORY
W/O MEMORY
WARNING SYSTEM SWITCH
Go to component -> Instrument illumination circuit (2 of 3) -> WARNING SYSTEM SWITCH
