Nissan Pathfinder IV facelift (2016-2020) w/ left, right front auto up/down wiring diagram
This page shows the only wiring diagram for the component.w/ left, right front auto up/down, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ left, right front auto up/down wiring diagram (1 of 1)
BETWEEN FULL STROKE FULL STROKE LOCK, N SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CARGO LAMP
DOOR
DOOR ON
FRONT ROOM/MAP LAMP ASSEMBLY
GRN WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR SWITCH (ALL)
INTERIOR SWITCH (DOOR)
KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT MAP LAMP SWITCH
LEFT PERSONAL LAMP
LEFT VANITY LAMP (IF EQUIPPED)
LOCK UNLOCK
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (W/ LEFT, RIGHT FRONT AUTO UP/DOWN)
OFF
ON OFF
POWER WINDOWS SYSTEM
RED WIRE
RIGHT END OF DASH)
RIGHT MAP LAMP SWITCH
RIGHT PERSONAL LAMP
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (W/ LEFT, RIGHT FRONT AUTO UP/DOWN)
RIGHT VANITY LAMP (IF EQUIPPED)
UNLOCK BETWEEN SWITCH FULL FULL STROKE STROKE, N
UNLOCK LOCK
W/ LEFT, RIGHT FRONT AUTO UP/DOWN
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> W/ LEFT, RIGHT FRONT AUTO UP/DOWN
