Nissan Pathfinder IV facelift (2016-2020) vias ctrl sol vlv 2 Wiring diagram
This page shows the only wiring diagram for the component.vias ctrl sol vlv 2, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vias ctrl sol vlv 2 (1 of 1)
A/F 1 (BANK 1)
A/F 1 (BANK 2)
A/F SENS 1
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CTRL CLOSE
CTRL OPEN
ECM RELAY
ECM RLY
ENG MOUNT CTRL VLV
FUEL PMP RLY
FUEL PUMP RELAY
FUSE 38
FUSE 39
FUSE 40
FUSE 44
FUSE 45
FUSE 46
FUSE 47
FUSE 55
FUSE 56
GRN WIRE
GRY WIRE
IGN SIG 3
IGN SIG 6
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
OIL PRESS CTRL VLV
OXY SENS (BANK 2)
PNK WIRE
PNP SIG
PPL
RED WIRE
SENS GND
SHIELD
THROT MTR RLY
THROTTLE CONTROL MOTOR RELAY
THROTTLE MTR +
VIAS CTRL SOL VLV 1
VIAS CTRL SOL VLV 2
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (4 of 7) -> VIAS CTRL SOL VLV 2
