Nissan Pathfinder IV facelift (2016-2020) right blind spot warning indicator shield, Wiring diagram
This page shows the only wiring diagram for the component.right blind spot warning indicator shield,, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right blind spot warning indicator shield, (1 of 1)
ADAS CONTROL UNIT, ADAS CONTROL UNIT SHIELD, BOSE SPEAKER AMP,
BLK WIRE
COOLING FAN CONTROL MODULE, LEFT FRONT COMBINATION LAMP
DISTANCE SENSOR (ICC SENSOR)
HOOD SWITCH
HORN (HIGH), HORN (LOW), RIGHT FRONT COMBINATION LAMP, RIGHT FRONT FOG LAMP
IGNITION COIL 6 (W/ POWER TRANSISTOR), CONDENSER 1
LEFT "C" PILLAR)
LEFT FRONT COMBINATION LAMP
LEFT FRONT FOG LAMP
LEFT HEADREST DISPLAY UNIT, LEFT FRONT LIFTING MOTOR,
LEFT POWER SEAT SWITCH, DRIVER SEAT CONTROL UNIT,
LEFT REAR LIFTING MOTOR
LEFT REAR POWER WINDOW SWITCH
LEFT SIDE CURTAIN AIR BAG MODULE SHIELD
REAR BLOWER MOTOR RESISTOR 2
REAR WINDOW DEFOGGER
RIGHT BLIND SPOT WARNING INDICATOR SHIELD,
RIGHT FRONT COMBINATION LAMP
RIGHT SIDE CURTAIN AIR BAG MODULE SHIELD
RIGHT SIDE RADAR, RIGHT BLIND SPOT
SHIELD
TRAILER)
WARNING/ INDICATOR
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> RIGHT BLIND SPOT WARNING INDICATOR SHIELD,
