Nissan Pathfinder IV facelift (2016-2020) ret back sens Wiring diagram
This page shows the only wiring diagram for the component.ret back sens, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ret back sens (1 of 1)
A/C COOL IND
A/C COOL SW
A/C CTRL GND
A/C HEAT IND
A/C HEAT SW
A/C IGN
A/C SW UNIT
BACK TED +HEAT
BLK WIRE
BLU WIRE
BRN WIRE
COOL
COOL IND
CUSH TED +HEAT
GND BLOWER
GRN WIRE
GRY WIRE
HEAT (+)
HEAT IND
ILLUMINATION
LT BLU WIRE
LT GRN WIRE
MID
NCA WIRE
OFF
PNK WIRE
PPL
RED WIRE
RET BACK SENS
RET CUSH SENS
RIGHT CLIMATE CONTROLLED SEAT BLOWER MOTOR
RIGHT CLIMATE CONTROLLED SEAT CONTROL UNIT
RIGHT CLIMATE CONTROLLED SEAT SWITCH
RIGHT END OF DASH)
RIGHT SEAT BACK THERMAL ELECTRIC DEVICE
RIGHT SEAT CUSHION THERMAL ELECTRIC DEVICE
SENS BACK
SENS CUSH
SENSOR
TAN WIRE
TED
VSPI BLOWER
WHT WIRE
YEL WIRE
Go to component -> Climate control seats circuit (2 of 2) -> RET BACK SENS
