Nissan Pathfinder IV facelift (2016-2020) lh shield Wiring diagrams
This page contains all the electrical diagrams for the component. lh shield, in which he is found in the car Nissan Pathfinder IV facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lh shield (1 of 4)
AUDIO HU
AUDIO HU IN+
BACK
BLK WIRE
BLU WIRE
BRN WIRE
CAM GND
CAM V
CAN L
CAN-H
COMBINATION SWITCH (SPIRAL CABLE)
COMP SHIELD
COMPUTER DATA LINES SYSTEM
DISPLAY
DISPLAY CONTROL UNIT
ENTER
FS CONT
GRN WIRE
GRY WIRE
GUIDE IN -
GUIDE OUT+
GUIDE SHIELD
IGN
ILL
IN/OUT
IN/OUT SHIELD
INSTRUMENT CLUSTER SYSTEM
LH PRE-
LH SHIELD
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MENU DOWN
MENU UP
MIC GND
MIC IN (+) SIG
MIC OUT GND
MIC OUT SHIELD
MIC OUT SIG
MIC VCC
MICROPHONE (IN OVERHEAD CONSOLE)
NAVIGATION SYSTEM
NS ON/OFF
PKB SIG
PNK WIRE
PPL
R CAM COMP
R CAM SHIELD
REAR VIEW CAMERA CIRCUIT
RED WIRE
REVERSE SIG
RH PRE-
RH SHIELD
RIGHT END OF DASH)
SHIELD
SOURCE
STEERING COLUMN)
STEERING SWITCHES
TAN WIRE
TEL
TEL OUT
TEL SHIELD
VOLUME DOWN
VOLUME UP
W/ TELEMATICS SYSTEM W/O TELEMATICS SYSTEM
W/O TELEMATICS SYSTEM
WHT WIRE
WHT/ BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ bose (3 of 7) -> LH SHIELD
