Nissan Pathfinder IV facelift (2016-2020) left touch sensor Wiring diagram
This page shows the only wiring diagram for the component.left touch sensor, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left touch sensor (1 of 1)
BACK DOOR
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPENER SWITCH
BACK DOOR SW
BACK DOOR WARNING CHIME
BAT POWER F/L
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CAN L
CAN-H
CINCH LATCH MOTOR
CLOSE SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR AJAR SWITCH
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK O
GRN WIRE
HALF SWITCH
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT TOUCH SENSOR
LT BLU WIRE
LT GRN WIRE
OPEN SW
OPEN SWITCH
OPENER SWITCH
PNK WIRE
PPL
RED WIRE
RED/GRN WIRE
REQUEST SW
REQUEST SWITCH
RIGHT TOUCH SENSOR
SHIELD
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ HEATED STEERING WHEEL, MEMORY W/O HEATED STEERING WHEEL, MEMORY
WHT WIRE
Go to component -> Back door circuit, w/ automatic back door system (2 of 2) -> LEFT TOUCH SENSOR
