Nissan Pathfinder IV facelift (2016-2020) left second row heated seat switch Wiring diagram
This page shows the only wiring diagram for the component.left second row heated seat switch, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left second row heated seat switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
ILL
LEFT "C" PILLAR)
LEFT SECOND ROW HEATED SEAT SWITCH
LEFT SECOND ROW SEAT HEATER
LEFT SECOND ROW SEAT HEATER (BACK)
LEFT SECOND ROW SEAT HEATER (CUSHION)
LOW HIGH OFF
LOW OFF
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT SECOND ROW HEATED SEAT SWITCH
RIGHT SECOND ROW SEAT HEATER
RIGHT SECOND ROW SEAT HEATER (BACK)
RIGHT SECOND ROW SEAT HEATER (CUSHION)
YEL WIRE
Go to component -> Heated seats circuit (2 of 2) -> LEFT SECOND ROW HEATED SEAT SWITCH
