Nissan Pathfinder IV facelift (2016-2020) left front power socket Wiring diagram
This page shows the only wiring diagram for the component.left front power socket, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front power socket (1 of 1)
ACCESSORY RELAY 1
ACCESSORY RELAY 2
AIR CONDITIONING SYSTEM
AIR CONDITIONING, INSTRUMENT CLUSTER, MIRRORS, NAVIGATION, SOUND SYSTEMS
AIR CONDITIONING, SEATS SYSTEMS
ANTI-THEFT, WARNING, DOOR LOCKS, BODY COMPUTER SYSTEMS
BLK WIRE
BLU WIRE
BODY COMPUTER SYSTEM
CONSOLE POWER SOCKET
DOOR LOCKS, ANTI-THEFT, BODY COMPUTER SYSTEMS
ENGINE CONTROLS, AIR CONDITIONING, CRUISE CONTROL SYSTEMS
EXTENDED STORAGE SWITCH
FROM BCM (BODY CONTROL MODULE) (DIAGRAM 3 OF 4)
FROM FUSE, FUSIBLE LINK, RELAY BOX 1 (DIAGRAM 1 OF 4)
FROM FUSE, FUSIBLE LINK, RELAY BOX 2 (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 4)
FRONT BLOWER MOTOR RELAY
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 25
FUSE 3
FUSE 30
FUSE 4
FUSE 9
GRN WIRE
GRY WIRE
IGNITION RELAY 2
LEFT FRONT POWER SOCKET
LT GRN WIRE
NAVIGATION, SOUND SYSTEMS
PNK WIRE
PPL
REAR CARGO POWER SOCKET
REAR USB CHARGE PORT
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT POWER SOCKET (CIGARETTE LIGHTER)
SEATS, NAVIGATION, AIR CONDITIONING, COMPUTER DATA LINES SYSTEMS
TAN WIRE
TO FUSE 18 (DIAGRAM 3 OF 4)
TO FUSE 29 (DIAGRAM 3 OF 4)
TO PUSH BUTTON IGNITION SWITCH (DIAGRAM 3 OF 4)
WARNING, DOOR LOCKS, ANTI-THEFT, COMPUTER DATA LINES, TRANSMISSIONS SYSTEMS
WHT WIRE
WIPER/WASHER, BODY COMPUTER SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> LEFT FRONT POWER SOCKET
