Nissan Pathfinder IV facelift (2016-2020) latch mtr open Wiring diagram
This page shows the only wiring diagram for the component.latch mtr open, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram latch mtr open (1 of 1)
AUTO UNLK REG
AUTOMATIC BACK DOOR CLOSE SWITCH
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC BACK DOOR SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN L
CAN SHIELD
CAN-H
CIRCUIT BREAKER 1
CLOSE SW
COMPUTER DATA LINES SYSTEM
DRIVER SW
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK N
GRY WIRE
HALF LATCH SW
HOT AT ALL TIMES
INSIDE CLOSE SW
KICK SENS GND
KICK SENS PWR
KICK SENS SERIAL
KICK SENS SERIAL SIG
LATCH MTR CLOSE
LATCH MTR OPEN
LEFT SPINDLE UNIT
LH A SIGN
LH B SIGN
LH MTR CLOSE
LH MTR OPEN
LH POWER
LH TOUCH SENS
LOWER MOTION ACTIVATED BACK DOOR SENSOR
LT BLU WIRE
LT GRN WIRE
MAIN SW
NOISE SHIELD LATCH
OPEN SW
PNK WIRE
PPL
RED WIRE
RH A SIGN
RH B SIGN
RH MTR CLOSE
RH MTR OPEN
RH POWER
RH TOUCH SENS
RIGHT END OF DASH)
RIGHT SPINDLE UNIT
SENS IN
SENS OUT
SHIELD
SPINDLE MOTOR
TAN WIRE
TOUCH SENS GND
UPPER MOTION ACTIVATED BACK DOOR SENSOR
WHT WIRE
YEL WIRE
Go to component -> Back door circuit, w/ automatic back door system (1 of 2) -> LATCH MTR OPEN
