Nissan Pathfinder IV facelift (2016-2020) crash zone sensor Wiring diagram
This page shows the only wiring diagram for the component.crash zone sensor, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crash zone sensor (1 of 1)
ACU COMM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
BUCKLE SW
COMPUTER DATA LINES SYSTEM
CRASH ZONE SENSOR
FRONT INNER OCCUPANT CLASSIFICATION SYSTEM SENSOR
GRY WIRE
IGN
K LINE
LAP BELT
LEFT FRONT DOOR SATELLITE SENSOR
LEFT FRONT SEAT BELT PRE-TENSIONER
LEFT FRONT SIDE AIR BAG MODULE
LEFT SIDE CURTAIN AIR BAG MODULE
LT BLU WIRE
LT GRN WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
PPL
REAR INNER OCCUPANT CLASSIFICATION SYSTEM SENSOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR SATELLITE SENSOR
SENS FI GND
SENS FI SIG
SENS FI VCC
SENS RI GND
SENS RI SIG
SENS RI VCC
SHIELD
SHOULDER BELT
TAN WIRE
W/ OCCUPANT CLASSIFICATION SYSTEM
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> CRASH ZONE SENSOR
