Nissan Pathfinder IV facelift (2016-2020) back door switch Wiring diagram
This page shows the only wiring diagram for the component.back door switch, which is found in the car Nissan Pathfinder IV facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back door switch (1 of 1)
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPEN OUT
BACK DOOR OPEN SW
BACK DOOR OPENER SWITCH
BACK DOOR REQUEST SW
BACK DOOR SW
BACK DOOR SWITCH
BAT BCM FUSE
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
OPENER ACTUATOR
OPENER SWITCH
PNK WIRE
PPL
RED WIRE
REQUEST SWITCH
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Back door circuit, w/o automatic back door system -> BACK DOOR SWITCH
