Car Wiring Diagrams for Starting circuit for Nissan Pathfinder III facelift (2010-2014)

4.0L A/T ASSEMBLY TCM (TRANSMISSION CONTROL MODULE) BATTERY FUSIBLE LINK BOX (BATTERY) (NEAR BATTERY) BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE COMPUTER (RIGHT FRONT DATA LINES OF ENGINE SYSTEM COMPT) CPU IGN SW GND CAN CAN GND (SIG) (PWR) FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSIBLE LINK J HOT IN ON OR START IGNITION FUSE 52 FUSE 53 RELAY IGNITION SWITCH INHIBIT IPDM E/R (RIGHT REAR OF ENGINE COMPT) OFF PNK WIRE RED WIRE RELAY 2 1 TR AT- SW 3 SW 4 PN SW STARTER MOTOR STARTER RELAY TR TR TR SW 2 SW 1 WHT WIRE WHT/GRN WIRE
