Nissan Pathfinder III facelift (2010-2014) transfer control Wiring diagram
This page shows the only wiring diagram for the component.transfer control, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer control (1 of 1)
5 4 PNK WIRE
AUTO
AUTO LOCK
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH PRESSURE SOLENOID VALVE ATP SWITCH
DEVICE (ON LEFT SIDE OF TRANSFER CASE)
DIODE 1 (BEHIND LEFT SIDE OF DASH)
FUSE 57
FUSE 58
FUSE 59
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSE, RELAY BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK J
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
LINE PRESSURE SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
OFF OFF
ON ON
ORG/ WIRE
PNK 1 2 WIRE
PNK WIRE
PPL
RED WIRE
RED(OR PNK) WIRE
SHIFT SWITCH
TRANSFER (ON LEFT REAR OF TRANSFER CASE) TERMINAL CORD ASSEMBLY
TRANSFER CONTROL
TRANSFER DROPPING RESISTOR (AT RIGHT KICK PANEL)
TRANSFER FLUID CLUTCH PRESSURE SWITCH SOLENOID VALVE TEMP SENSOR
TRANSFER MOTOR RELAY
TRANSFER SHIFT HIGH RELAY
TRANSFER SHIFT LOW RELAY
TRANSFER SHUT OFF RELAY (IN FUSE, RELAY BOX)
TRANSFER TERMINAL CORD ASSEMBLY
WAIT DETECTION SWITCH SWITCH (ON LEFT FRONT OF TRANSFER CASE)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> 4wd circuit, all mode 4wd (2 of 2) -> TRANSFER CONTROL
