Nissan Pathfinder III facelift (2010-2014) rr def status v ref return pnk Wiring diagram
This page shows the only wiring diagram for the component.rr def status v ref return pnk, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr def status v ref return pnk (1 of 1)
21 22 23 24 25 26 PPL PANEL/FLOOR FD BCK BLEND DOOR FD BCK
39 40 28 27 CAN-H CAN-L FAN SW AIRCON SW PNK WIRE
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
FR BLWR MONITOR VB GND
FRONT AIR CONTROL
FRONT AIR MIX DOOR MOTOR (BEHIND CENTER OF DASH)
FRONT BLOWER MOTOR RELAY (IN FUSE, RELAY BOX)
FRONT BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH)
FRONT BLOWER SWITCH
FUSE 19
FUSE 24
FUSE 27
FUSE 8
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH)
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL+ ILL- A/C REQUEST RR DEF REQ EVAP AIR TEMP SENS SENS RETURN PANEL/FLOOR CCW
INTAKE DOOR MOTOR (BEHIND GLOVE BOX, ON HEATER INTAKE UNIT)
INTAKE SENSOR (BEHIND CENTER OF DASH, ON COOLING UNIT)
LT BLU WIRE
MODE DOOR MOTOR (BEHIND CENTER OF DASH, ON HEATER UNIT)
OFF
ORG/ WIRE
PNK 3 2 1 5 6 WIRE
PNK PPL 2 4 3 6 1 WIRE
PPL
RED WIRE
RED/YEL WIRE
RR DEF STATUS V REF RETURN PNK WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> RR DEF STATUS V REF RETURN PNK WIRE
