Nissan Pathfinder III facelift (2010-2014) ppl input 3 Wiring diagram
This page shows the only wiring diagram for the component.ppl input 3, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl input 3 (1 of 1)
+IG
70 68 BAT (F/L) PWR WIN PWR SPLY (RAP)
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN-L CAN-H
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPT) TAIL LAMP RELAY
COMPUTER DATA LINES SYSTEM
CPU TAIL/L RLY
FUSE 37
FUSE FUSE 52
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK G
GND PWR
GND SIG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN SW
IGNITION RELAY
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
IPDM E/R (RIGHT REAR OF ENGINE
LEFT REAR POWER WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
PNK CAN-L WIRE
PNK INPUT 5 WIRE
PNK WIRE
PPL
PPL INPUT 3
PPL PPL
RED WIRE
RIGHT REAR POWER WINDOW SWITCH
WHT WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> PPL INPUT 3
