Nissan Pathfinder III facelift (2010-2014) lock unlock switch switch Wiring diagram
This page shows the only wiring diagram for the component.lock unlock switch switch, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock unlock switch switch (1 of 1)
70 56 57 63 67 BAT (F/L) BAT SAVER OUT BAT (FUSE) ROOM LAMP GND (PWR)
BACK DOOR LATCH (DOOR AJAR SWITCH) (CENTER OF BACK DOOR)
BCM (UNDER LEFT SIDE OF DASH)
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
BRN WIRE
CARGO LAMP
COMPUTER DATA LINES SYSTEM
CPU LOCK
DOOR
DOOR OFF ON
FULL FULL STROKE STROKE
FUSE 1
FUSE 25
FUSIBLE LINK G
GLASS HATCH AJAR SWITCH (CENTER OF BACK DOOR)
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE 18
HOT AT ALL TIMES FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) FUSE 31
HOT IN ON OR START
IGNITION KEYHOLE ILLUMINATION
KEY CYL LOCK SW
KEY CYL UNLOCK SW
KEY SWITCH
KEY SWITCH, IGNITION KNOB SWITCH
LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) (REAR OF DRIVER'S DOOR)
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR)
LEFT VANITY LAMP (W/ VANITY LAMPS)
LOCK UNLOCK SWITCH SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
OFF
ON FRONT ROOM/MAP LAMP ASSEMBLY
ON OFF
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR)
RIGHT VANITY LAMP (W/ VANITY LAMPS)
SERIAL LINK PPL
UNLOCK
W/ INTELLIGENT KEY SYSTEM
W/ PERSONAL MAP LAMPS
W/O INTELLIGENT KEY SYSTEM
W/O PERSONAL LAMPS
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> LOCK UNLOCK SWITCH SWITCH
