Nissan Pathfinder III facelift (2010-2014) lock unlock lock/ unlock switch cpu Wiring diagram
This page shows the only wiring diagram for the component.lock unlock lock/ unlock switch cpu, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock unlock lock/ unlock switch cpu (1 of 1)
47 48 42 43 DOOR SW (DR) DOOR SW (RL) GLASS HATCH SW BACK DOOR SW PNK WIRE
57 70 67 BAT (FUSE) BAT (F/L) GND (PWR)
BACK DOOR LATCH (CENTER OF BACK DOOR)
BCM (UNDER LEFT SIDE OF DASH)
BETWEEN FULL STROKE, N FULL STROKE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CPU +B CAN HRN
FUSE 30
FUSE 34
FUSE 35
FUSE 40
FUSE 41
FUSE 52 FUSE 53
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK BOX (BATTERY) (NEAR BATTERY)
FUSIBLE LINK C
GRN WIRE
GRY WIRE
HEADLAMP LOW RELAY
HEADLIGHTS SYSTEM
HORN (LEFT FRONT OF ENGINE COMPT)
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGN CAN
IGNITION RELAY
IPDM E/R (RIGHT REAR OF ENGINE COMPT)
LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH)
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT HEADLAMP HIGH RELAY
LOCK SWITCH
LOCK UNLOCK LOCK/ UNLOCK SWITCH CPU
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
ORG/ WIRE
PNK PPL WIRE
PNK WIRE
PPL
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT POWER WINDOW, DOOR
RIGHT REAR DOOR SWITCH
UNLOCK LOCK
UNLOCK SWITCH
WHT WIRE
WHT/RED WIRE
Go to component -> Forced entry circuit, with intelligent key unit (2 of 2) -> LOCK UNLOCK LOCK/ UNLOCK SWITCH CPU
