Nissan Pathfinder III facelift (2010-2014) gnd data rx lcd data tx dvd gnd filtered batt Wiring diagram
This page shows the only wiring diagram for the component.gnd data rx lcd data tx dvd gnd filtered batt, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd data rx lcd data tx dvd gnd filtered batt (1 of 1)
1 2 3 4 AUX AUD RH+ AUX GND
8 7 6 5 2 1 CD DVD EJECT SW GND M CAN 1 L M CAN 1 H
A/C, AV SWITCH ASSEMBLY
ANT MAIN ANT +B
ANTENNA AMPLIFIER
AUD BUS RH- AUD BUS RH+
AUX AUD LH+
AUX IN JACK
AV CONTROL UNIT
BACKUP LAMP RELAY (IN FUSE, RELAY BOX)
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA
CD EJECT IGN REV SIG PKB SIG
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA RX 1
DVD PLAYER (IF EQUIPPED)
FES L- OUT
FES R- OUT
GND DATA RX LCD DATA TX DVD GND FILTERED BATT
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
LEFT RIGHHT WINDOW WINDOW ANTENNA ANTENNA GRID GRID
LT BLU WIRE
LT GRN WIRE
M-CAN 2 H
M-CAN 2 L
NCA WIRE
ORG/BLU WIRE
PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
PNK PNK WIRE
PNK WIRE
PPL
PPL PNK WIRE
REAR VIEW CAMERA (CENTER OF BACK DOOR)
RED WIRE
REV SIG
SHIELD
SHIELD SHIELD
SHIELD SHIELD SHIELD
SW GND
SW PWR +5
TEL VOICE - TEL VOICE +
UNIFIED METER CONTROL UNIT PNK (W/ INFORMATION DISPLAY) WIRE
VIDEO IN- VIDEO IN+
VIDEO MONITOR (W/ DVD ENTERTAINMENT SYSTEM)
VIDEO OUT
VTR+
VTR- VTR+ COMP 1 IN +
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Bose radio circuit, without navigation (4 of 4) -> GND DATA RX LCD DATA TX DVD GND FILTERED BATT
