Nissan Pathfinder III facelift (2010-2014) fuse, fusible link box (right rear of engine Wiring diagram
This page shows the only wiring diagram for the component.fuse, fusible link box (right rear of engine, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse, fusible link box (right rear of engine (1 of 1)
+IG
BACK DOOR OPEN SWITCH (CENTER OF BACK DOOR)
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
COMBINATION METER
COMPT)
COMPUTER DATA LINES SYSTEM
CPU H/LP H/LP HI LO ANTI THEFT HORN
DOOR AJAR IND
FUSE 30
FUSE 52 FUSE 53
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE
FUSIBLE LINK BOX (BATTERY) (NEAR BATTERY)
FUSIBLE LINK C
GND CAN CAN (PWR)
GRN WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
IPDM E/R (RIGHT REAR OF ENGINE COMPT)
KEY IND
LOCK
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER SELECT UNLOCK RELAY (BEHIND RIGHT END OF DASH)
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT DOOR REQUEST SWITCH
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
WHT/GRN WIRE
Go to component -> Power door locks circuit, with intelligent key unit (2 of 3) -> FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE
