Nissan Pathfinder III facelift (2010-2014) front variable blower control Wiring diagram
This page shows the only wiring diagram for the component.front variable blower control, which is found in the car Nissan Pathfinder III facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front variable blower control (1 of 1)
1 2 3 4 5 6 7 8 9 10 GROUND
18 27 28 39 40 PNK KEYLESS TUNER GND AIRCON SW BLOWER FAN SW CAN-H CAN-L WIRE
2 4 3 1 MOTOR - MOTOR + SET POINT GROUND
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLOWER SPD POT TEMP POT V REF RETURN
BLU WIRE
COMPUTER DATA LINES SYSTEM
FRONT BLOWER MOTOR RELAY (IN FUSE, RELAY BOX)
FRONT VARIABLE BLOWER CONTROL
FUSE 11 FUSE 10
FUSE 24
FUSE 27
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH)
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTERIOR LIGHTS SYSTEM ILL +
LT BLU WIRE
LT GRN WIRE
MOTOR - MOTOR + GROUND SET POINT
ORG/ WIRE
PNK WIRE
REAR AIR CONTROL (FRONT)
REAR AIR CONTROL (REAR)
REAR BLOWER MOTOR (RIGHT SIDE OF CARGO AREA)
REAR BLOWER MOTOR RELAY
REAR VARIABLE BLOWER CONTROL
RED WIRE
RED/YEL WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> FRONT VARIABLE BLOWER CONTROL
