Nissan Pathfinder III facelift (2010-2014) delta stroke sensor Wiring diagram

1 3 5 PWR_SUP GND SIG 12 11 13 PNK WIRE 3 1 4 5 2 PWR BATT CAN-H CAN-L GND 4 1 2 3 CLU P CLU GND CAN-L CAN-H ABS IND. ACTIVE BOOSTER (LEFT REAR OF ENGINE COMPT) BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE IND BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DELTA STROKE SENSOR FUSE 14 FUSE 18 FUSE BLOCK (J/B) (BEHIND RIGHT END FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK L FUSIBLE LINK N GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE OF DASH) ORG/ WIRE PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH) PNK WIRE RED WIRE RED/YEL WIRE RIGHT END OF DASH) SIDE OF DASH) SLIP IND STEERING ANGLE SENSOR (BEHIND LEFT UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) VDC OFF IND VDC OFF SWITCH WHT WIRE WHT/GRN WIRE WHT/RED WIRE YAW RATE/SIDE/DECEL G SENSOR (BELOW REAR OF CENTER CONSOLE) YEL WIRE
